Conservatories Online are pleased to introduce a new type of double-glazed sealed unit - Warm-a-Glass™

Warm-a-Glass™ construction uses Pilkington K low emissivity coated glass with integral dual sealed thermally broken spacer bar to create thermally efficient double glazing units. The unique design of the spacer and the material used reduces the hot or cold temperatures from transferring to the inside. Typical U-values (Wm2K) of 1.7 or 1.4 when argon filled is achieved.

Benefits

Detail illustration of integral dual sealed thermally broken spacer bar Glazing Type Cavity Filling U-value (Wm2K) Double Glazed Annealed Glass Air 1.7 Double Glazed Annealed Glass Argon 1.4 U-values quoted for Warm-a-Glass™ are computer simulations supplied by Azon USA inc. usings NFRC environmental conditions for North America. Outside temperature = -18°C Indoor temperature = +21°C. Wind speed 15mph (24 kph). Based on 4mm glass with 12mm cavity. Glass Weight Double Glazed Units with 12 mm cavity Weight (kg/m2) 4 - 12 - 4 20 6 - 12 - 6 30 10 - 12 - 6 40 12 - 12 - 6 45

Designed specially to reduce heat loss through glass Highly effective Pilkington K low emissivity glass (emissivity less than 0.2) Pilkington K Low emissivity coating allows the free shortwave energy from the sun to enter the building, but acts as a barrier to the escape of expensive longwave energy from internal heat sources Unique spacer bar works like a thermal break decreasing the thermal transfer from outside air to the inside of the room and alters the condition in which condensation normally occurs thus reducing significantly the occurence of moisture forming on the glass Warm-a-Glass™ provides excellent thermal insulation characteristics by reducing heat loss by 30% over ordinary double glazing Warm-a-Glass™ can be combined with solar glass to offer full environmental control solutions Insulating units incorporating Warm-a-Glass™ are as efficient as triple glazing and can achieve U values of 1.5W/m2K Warm-a-Glass™ can be combined with solar control glasses to offer full environmental control solutions Neutral colour in transmission and reflection Larger windows can be specified in domestic and commercial Spacer bars available in 3 colours - gold, bronze and silver
